ED41000P2-01 (ED4100 serisi)
4xDB9M serial ports; 2xRS-232, 2xRS-232/422/485, 10/100 RJ45 Ethernet, PoE, customizable through Evolution SDK, international power supply and regional adapters, 100-240VAC
Datasheet Link : ED41000P2-01
EDS4100, kurumsal düzeyde ağ uygulamaları göz önünde bulundurularak tasarlanmış, seri arabirimli hemen hemen her cihaza güvenli ağ bağlantısı eklenmesini sağlayan bir çözümdür. 4-port’lu ve PoE de dahil olmak üzere esnek güç seçenekleri ile donatılmış olan EDS4100, çok sayıda ekipmanın bağlanması, uzaktan erişilmesi ve yönetilmesi gereken uygulamalar için idealdir. SSL / SSH, AES, 3DES ve RC4 şifreleme gibi sağlam güvenlik seçeneklerine sahiptir. EDS4100, esnek bir "Cisco benzeri" CLI'yi destekler ve yapılandırma ve kontrolü basitleştiren, tıbbi cihazlar, kiosklar, POS / perakende terminalleri gibi uç cihazları entegre etmeyi kolaylaştıran dahili bir web sunucusu ile donatılmıştır.
- Cisco benzeri CLI, XML ve RSS'yi destekleyen, programlanabilir platform
- Kullanıma hazır güvenlik algoritmaları ve şifreleme modülleri
- Esnek güç seçenekleri
ÜRÜN SİPARİŞ KODLARI :
|
4xDB9M serial ports; 2xRS-232, 2xRS-232/422/485, 10/100 RJ45 Ethernet, PoE, customizable through Evolution SDK, no power supply |
|
|
ED41000P2-01 |
4xDB9M serial ports; 2xRS-232, 2xRS-232/422/485, 10/100 RJ45 Ethernet, PoE, customizable through Evolution SDK, international power supply and regional adapters, 100-240VAC |
Serial Interface
- Connectors: 4 x DB9M; 2 x RS232, 2 x RS232/422/485
- Data Rates: 300 bps to 921.6 Kbps
- Characters: 7 or 8 data bits
- Stop Bits: 1 or 2
- Parity: Odd, even, none
- Stop Bits: 1 or 2
- Flow Control: CTS/RTS, XON/XOFF
Ethernet Interface
- Software selectable Ethernet speed 10/100/Auto
- Software selectable Half/Full/Auto duplex
- Interface: 10Base-T/100Base-T
- Speed: 10Base-T/100Base-T
- Connector: RJ45
- Standards: ARP, UDP, TCP, ICMP, Telnet, SNMP, DHCP, BOOTP, TFTP, Auto IP, SMTP, FTP, DNS, Traceroute and HTTP
Security
- SSL v3, SSH v2
- MD5, SHA-1, Base-64
- AES 128-bit encryption
- 3DES encryption
- RC4 128-bit encryption
- Password protection, IP filtering
Indicators (LED)
- Power, Link, Activity, RX Activity, TX Activity
Processor
- CPU: Intel XScale IXP420 @ 266MHz
- Memory: 32 MB SDRAM, 8 MB Flash
Power Requirements
- Barrel Connector: 9-30 VDC
- Screw Terminal: 42-56 VDC
- Power: 5.4 W (450 mA @ 12Vdc)
- PoE: 802.3af compliant
Environmental Limits
- Operating temperature: 0° to 55°C (32° to 131°F)
- Storage temperature: -40° to 70°C (-40 to 158°F)
- Operating Humidity: 10% to 90%
- Storage Humidity: 10% to 90%
Form Factor
- Housing: Metal enclosure with removable wall mounts
- Dimensions (LxWxH): 3.81 x 17.65* x 12.7 cm (1.5 x 6.95* x 5 in)
- * With wall mounts = 20.14 cm (7.93 in)
- Weight: 0.86kg (1.9lbs)
Agency Approvals
- FCC, CUL, UL, VCCI, CE, CSA, TUV, C-Tick, GS, CB Scheme
Warranty
- 2-year limited warranty
Shipping Dimensions
- Dimensions (LxWxH): 242 x 191 x 115 mm (9.5 x 7.5 x 4.5 in)
- Weight: 1.44kg (3.19lbs)
Software
- Windows 98/ME/NT/2000/XP/Vista (32-bit versions) DeviceInstaller configuration software, Com Port Redirector software and related utilities
- Management Options: Web browser, Telnet client, Serial Terminal, SNMP v2 (MIBII, RS232MIB), XML
Regulatory
- FCC Part 15 Subpart B Class A
- ICES-003 Issue 4 February 2004 Class A
- AS/NZS CISPR 22: 2004 Class A
- EN55022: 1998 + A1: 2000 + A2: 2003 Class A
- VCCI V-3/2006.4 Class A
- EN61000-3-2: 2000 Class A
- EN61000-3-3: 1995 + A1: 2001
- EN55024: 1998 +A1: 2001 +A2: 2003
- IEC_61000-4-2: 1995 8KV Air, 4KV Contact
- IEC_61000-4-3: 1995 3.0V/m, 1KHz AM Sine Wave at 80%
- IEC_61000-4-4: 1995 1.0KV Power Lines, 0.5KV I/O Lines
- IEC_61000-4-5: 1995 1.0KV Common, 1.0 KV Differential
- IEC_61000-4-6: 1996 3.0 Vrms, 80% AM Modulated (1KHz)
- IEC_61000-4-8: 1993 50Hz 1.0 Arms/m
- IEC_61000-4-11: 1994 (>95%,0.5), (30%,25), (>95%,250)
Isolation
- Power Input: 2KV common mode and 1KV differential mode power surge protection
- Serial Port(s): 15 KV ESD protection
- Ethernet Port: 1500 VAC isolation shielded
