Datasheet
M-2601
16 DOs, source, 24 VDC, 0.5A
| Digital Outputs | 16 channels, source type |
| Output Voltage Range | 24 VDC nominal, min. 11 VDC to max. 28.8 VDC |
| On-state Voltage Drop | Max. 0.3 VDC @ 25°C |
| On-state Current | Min. 1 mA per channel |
| Off Leakage Current | Max. 50 µA |
| Current Rating |
• 0.5 A per channel • 4 A per common |
| Common Type | 16 channels for 2 COMs (single common) |
| Power Consumption | 80 mA @ 5 VDC |
